LED Panel Size

65”, 75”, 86”

Backlight Type

LED (DLED)

Resolution(H×V)

3840×2160 (UHD)

Color

10 bit 1.07B

Brightness

400cd/m2

Contrast

4000:1 (according to panel brand)

Viewing angle

178°

Display protection

4 mm tempered explosion-proof glass

Backlight lifetime

50000 hours

Speakers

15W*2 / 8Ω

Operating System

Android System

Android 11.0//12.0/13.0 as optional

CPU (Processor)

Quad Core 1.9/1.2/2.2GHz

Storage

RAM 4/8G; ROM 32/64/128G as optional

Network

LAN/ WiFi

Windows System (OPS)

CPU

I5 (i3/ i7 optional)

Storage

Memory: 8G (4G/16G optional) ; Hard Disk: 256G SSD (128G/512G/1TB optional)

Network

LAN/ WiFi

OS

Pre-install Windows 10/11 Pro

Touch technology

Capacitive touch; 20 points; HIB Free drive

Response speed

≤ 5ms

Operation system

Support Windows, Android, Mac OS, Linux

Working temperature

0℃~60℃

Operating Voltage

DC5V

Power consumption

≥0.5W

Max Power

≤250W

≤300W

≤400W

Standby power

≤0.5W

Voltage

110-240V(AC) 50/60Hz

Input ports

AV , YPbPR , VGA , AUDIO  ,HDMI*2, LAN(RJ45)

Output Ports

SPDIF , Earphone

Other Ports

USB2.0 , USB3.0 ,RS232 ,Touch USB

Function buttons

Power

Accessories

Power cable*1;Remote Control*1; Touch Pen*1; Instruction manual*1 ; Warranty card*1; Wall brackets*1 set
